Parametric Tray P004 v1.0.0

Name: Parametric Tray P004
Brand: Vasily39
SKU: PARAM-004
Availability: InStock

Free Template

WidthOuter 106.0 mm

LengthOuter 156.0 mm

HeightOuter 33.0 mm

Sheet thickness Measured mm

Measure your sheet with calipers for a tight fit.

Part names on the sheet

SVG, kerf 0 and 0.15 mm · LightBurn, LaserGRBL, CorelDRAW, Illustrator

Parametric Tray P004. Parametric design: set the size and material thickness, then download a cutting file made for you (laser machine, co2 or diode).

Design your own rectangular tray in seconds. Set the inner or outer dimensions and your material thickness, check the live 3D preview, and download a cut-ready SVG.

5 parts: a bottom plate and 4 walls
Inner width and length: 20–600 mm
Inner height: 10–600 mm
Material thickness: 1–25 mm (plywood, MDF, acrylic and more)
Inner and outer dimensions shown side by side. Type either one and the other updates.
Finger joints on the corners and tabs into the bottom plate are generated automatically for any size, so the parts fit together without adjustments.
The bottom is flush with the outer walls, so the tray has a clean look.
The SVG has a labeled part layout: cut lines in red, and the material and dimensions in the header.

Great for desk organizers, workshop and kitchen trays, drawer inserts, serving trays and storage.

AttentionThis is not a physical product, these are digital files for manufacturing products on a CNC laser machine. While using this file, you can create finished product for own or commercial use. Resale of digital files and their distribution is prohibited.
